• On grid: 6kW.
• Back up: 5kW.
• Input voltage: 40~60Vdc.
• 2 MPPT trackers, 9kW max.
• UPS level switching <10ms.
• Support Intelligent shutoff.
• IP class: IP65.
• DC Surge class 2 protection. DC ARC protection.
Topband TBE series inverter can meet the needs of grid-connected and off-grid systems at the same time. It can not only realize grid-connected and off-grid functions but also realize bidirectional control of electric energy.
ModelP1-5000HI
Max. recommended PV power7500W
Max. DC voltage600V
Start voltage58V
Nominal voltage360V
MPPT voltage range60V~550V
Strings per MPPT tracker2
Max. short-circuit current per MPPT trackers16A
AC nominal power5000W
Max. AC apparent power5000VA
Nominal AC voltage220V/230V/240V
AC grid frequency50/60Hz
Max. output current22.7A
Adjustable power factor0.8leading…0.8lagging
THDi
<3%
Single-phase | 5kW
Single-phase | 6kW
Three-phase | 15kW
Three-phase | 20kW
